D451

Support high-performance ABS material printing

  • Using rainbow runway 3D printing technology

  • High-efficiency continuous jet 3D printing technology

  • Desktop voxel-level color multi-material 3D printer

    A
    Full color printing
    J
    Large forming space
    D
    High-precision printing
    E
    High efficiency printing
    I
    Mix of 6 materials
    G
    Customized on demand
    H
    Low overall cost

Technical Reference

Basic configurationDetailed introduction
Highest resolution:600*600*1200dpi
Print head:2 teams
Printing channel:8 material channels
Number of nozzles:2560 nozzles
Material configuration:6 kinds of materials
Maximum forming size:Outer diameter φ450mm-inner diameter φ100mm height 150mm (circular area)
Forming platform specifications:1512cm2
Printing effect:Full color printing
transparent printing
soft and hard composite printing
Printing mode:Fast mode 42μm (monochrome)
Fine mode 21μm
Machine configurationDetailed introduction
physical dimension:860*650*790mm
Machine weight:200kg
operating system:Win7 / Win8 / Win8.1 / Win10, 64 bit
Support format:STL, PLY, WRL, OBJ, WJP (dedicated)
Internet connection:LAN ? TCP/IP
Power requirements:AC200-240V 50-60Hz
rated power:0.9KW
Operating environment:Temperature 20-30 °C (64-77 °F)
relative humidity 40-80% (non-condensing)

Certification:CE, FCC, RoHS

Detailed parameter download

Material recommendation

  • SUP series
    The materials are support materials, including standard support materials, alkali-soluble support materials, and hot-melt support materials, which provide support for the molding material during the printing process.
  • Medical series
    The materials are medical materials, including dental and biocompatible materials, which can be used in dental and medical guides.
  • FXL series
    The material is a flexible material, including transparent, cyan, magenta, yellow, white, black and other 6 colors, which are divided into standard flexible materials and super soft flexible materials, which can be printed with models of different hardness and functional simulation.
  • ABS series
    The material is ABS-like material, including 6 colors, including transparent, cyan, magenta, yellow, white, and black. It has excellent overall performance and can be used for functional color prototype printing.
  • RGD series
    The material is a universal hard material, including 6 colors of transparent, cyan, magenta, yellow, white, black, etc., which can be applied to the printing of conventional models such as high transparency and full color.
